Apollo Seiko BRC-2000 - Dimensions

12 pages

To Next Page

To Previous Page

page 6 of 12

I/O connector

Sludge Cup

BRC-3000

2-M3 spot facing(Rear side)

DC24V Jack

3. Dimensions

(Standard Type)

(Solder Spatter Preventing Type *A silicone sheet is attached.)

BRC-3000

2×M3Countersink(Fitting hole)
