4
APPLICATIONS
The Apollo Model 1500/1600 Swing Gate Operator is designed to handle swing
gates up to 16 feet in length and 600 pounds each. A professional fence or gate
dealer is recommended to assure proper installation. Apollo Gate Operators are
available only through qualified dealers with an outstanding reputation in the fence
and gate industry. These dealers will be able to recommend the proper equipment
for particular applications. Apollo Gate Operators are 12 Volt DC (Direct Current)
powered. A 12 Volt sealed battery (33ampere hour minimum) with connecting posts
located on the top is recommended. There are several advantages with 12 Volt DC
systems:
•
Low voltage virtually eliminates risk of electrical shock.
•
Battery powered operators provide up to 200 operations in the event of
power outages.
•
The battery may be recharged with a trickle charger or by solar energy
(eliminating the need for costly trenching to remote entrances).
If a trickle charger is used and a standard electrical outlet is not readily available, a
licensed electrician will be required for proper electrical hook up.
The following table should be used as a guide for capacity of operation of operators
only, additional options may reduce the the daily usage. Please note that the charge
capability of solar panels will vary with different geographical locations.
Daily Cycles 1-10 1-20 1-40 1-60 1-80 80+
5 watt solar panel
*
10 watt solar panel
*
20 watt solar panel (requires 5310 regulator)
*
30 watt solar panel (requires 5310 regulator)
*
40 watt solar panel (requires 5310 regulator)
*
1.5 amp battery charger
*
10 amp battery charger
*
Note: Double the amount of solar panels for Dual Gate Operators.
