TECHNICAL DATA
XP95 Manual Call Point
Specifications are typical
and given at 23°C and 50%
relative humidity unless
otherwise stated.
Call Point Type:
D
eformable element
Weight:
151g
Call Point Principle:
Operation of a switch
Alarm Indicator:
Red Light Emitting Diode (LED)
Fault Indicator:
Amber/yellow light emitting
diode (LED)
Type Code:
(2 1 0 4 3)
1 1 1 1 1
Supply Wiring:
Two-wire supply, polarity
sensitive
Loop connections L1/L2:
Terminal block
technical data
Operating Voltage:
17V-28V dc
Communication Protocol:
5V-9V peak to peak
Q
uiescent Current:
100µA
Power-up Surge Current:
1mA
M
aximum Power-up Time:
1 second
Alarm Current, LED
illuminated:
4
mA
Normal Analogue Value:
16
Alarm State Value:
64
Electro-magnetic
Compatibility:
See page 21 for full details
Temperature Range:
Max. continuous operating:
+60°C
Min. continuous operating:
0°C
Min. operating: -20°C
(no condensation/icing)
Storage: -30°C to +80°C
Humidity:
(No condensation)
0
to 95% relative humidity
Compliance Standard:
EN54-11:2001
EN54-17:2005 (isolated
v
ersion)
IP Rating:
24
Dimensions:
8
9mm x 93mm x 26.5mm
(manual call point)
87mm x 87mm x32mm
(back box)
Materials:
Housing: Red self-coloured
Polycarbonate/ABS
Hinged cover and locking
tag are also available, part
number: 26729-152
XP95 glasses are also
available, part number:
26729-154 (pack of 5)
