9
2-3 Electrical Specifications
Accuracy is ± (% reading + number of digits) at 23°C ± 5°C at less than 80% R.H.
(1) AC Voltage : Auto-ranging
Range Resolution Accuracy
Over voltage
protection
400.0mV
100μV ±(2.0% rdg + 5dgt ) 50Hz ~ 60Hz *
600V rms
4.000V 1mV
±(1.5% rdg + 5dgt ) 40Hz ~ 300Hz
40.00V 10mV
400.0V 100mV
600V 1V
±(1.5% rdg + 5dgt ) 40Hz ~ 500Hz
Input Impedance : ≧10MΩ // less than 100pF.
* Less than 30 digital rolling.
