22
MAINTENANCE
WARNING : TO AVOID ELECTRICAL SHOCKS REMOVE TEST LEADS FROM INSTRUMENT BEFORE
OPENING THE COVER.
4-1 General Maintenance
1. Repairs or servicing not covered in this manual should only be performed by qualified personal.
2. Periodically wipe the case with a dry cloth and detergent do not use abrasives or solvents.
4-2 Battery Installation or Replacement
The meter is powered by two 1.5V alkaline battery. Refer to Fig. 4 and use the following procedure to replace the battery.
1. Disconnect the test leads and turn the meter off. Remove the test leads from the front terminals.
2. Remove the battery cover of case bottom from the instrument by removing the screw and then lifting off battery cover.
3. Lift the battery from the battery box.
4. Reinsert the battery into the battery box.
5. Replace the battery cover and reinstall the screw.
