3-3 AC/DC Voltage Measurement
1. Turning the rotary switch at " V " or “V“ position.
2. Connect the black test lead to the "COM" terminal on the bottom of the meter and the red test lead to the
" V-Ω" terminal . You can now place the test probes on the conductors to make the measurement.
3-4 Resistance Measurement
1. Turning the rotary switch at "Ω
<" position.
2. Connect the black test lead to the "COM" terminal and red lead to the " V- Ω" terminal.
3. Verify that the power to the circuit under test is off. Connect test leads to the circuit to make the measurement.
4. Pressing the Ω /
< button to select Resistance mode or Continuity mode.
5. At
< mode, Built - in buzzer sounds if the resistance of the circuit under test is less than 50Ω between 50Ω
to 300Ω the buzzer maybe sound or off either.
