506/506B
EN
Continuity Check
CAUTION
• To avoid possible damage to the meter or to the equipment
under test, disconnect circuit power and discharge all high
voltage capacitors before testing continuity.
subtract this value.
High-resistance (>10MΩ) readings are susceptible to
electrical noise. To smooth out most noisy readings, enter
the MAX/MIN recording mode; then step to the average
(AVG) reading.
The continuity check features a buzzer that sounds as long
as a circuit is complete. The buzzer allows you to quick
continuity checks without watching the display.
When measuring resistance is less than threshold, the
buzzer sounds. You can setup the threshold in setup mode.
The continuity threshold is default 30Ω.
To use continuity check, turn the rotary switch to resistance
position, then press the function (yellow) button to select
measuring mode.
