The Meter Description
Front panel illustration :
1. Auto backlight sense point
2. 40,000 count dual display
3. Push buttons
4. Rotary switch
5. Input terminal for voltage, frequency, resistance,
continuity,diode, capacitance and temperature measurements.
6. Return terminal for all measurements.
7. Input terminal for 0 to 400mA current measurements.
8. Input terminal for 0 to 10A current measurements.
TRUE RMS
600V
CAT.III
1000V
MAX
FUSED
400mA
MAX
10A
FUSED
CAT.IV
COM
mA
V
A
Hz
AC+DC
A
AC+DC
V
AC+DC
mV
Hz
mV
LoZ
Auto V
V
Hz
OFF
P HOLDCANCEL
°C/°F
A HOLDENTERHFRRANGE
Hz
1
2
3
4
56
7
8
