23
4-3 Fuse Replacement
Refer to Figure 3 and the following procedure to examine or replace the meter’s fuse:
1. Perform steps 1 through 3 of the battery replacement procedure.
2. Than remove the two screws from the case bottom and lift the case bottom until it gently unsnaps from the case
top.
3. Remove the defective fuse by gently prying one end of the fuse loose and sliding the fuse out of the fuse holder.
4. Install a new fuse of same size and rating. Make sure the new fuse is centered in the fuse holder.
5. Replace the case top and case bottom and battery case bottom. Make sure that the battery leads do not be
come pinched between the case halves. Reinstall the three screws.
