3
Symbols in this Manual.
# This symbol indicates where cautionary or other information is found in the manual.
FUSE
Battery
1-2 Front Panel
Refer to Figure 1 and to the following numbered steps to familiarize yourself with the meter’s front panel controls
And connectors.
1. Digital Display — The digital display has a 3400 counts LCD readout with 70 segments analog bar graph, auto
polarity, decimal point, “ “ AC, DC RANGE, HOLD APO and unit annunciators.
2. Rotary Switch — Select the Function and Range desired.
3. COM Input Terminal — Ground input connector.
4. V
Ω
Hz Input Terminal — Positive input connector for Volts, Ohms and Frequency.
5. mA Input Terminal — Positive input connector for Amp measurements (up to 340mA).
6. A Input Terminal — Positive input connector for Amp measurements (up to 10A).
