Apple Cinema Display 22" (ADC) Views - 1
Block Diagram
Block Diagram
Block Diagram
USB Socket
Panel Signal Input
Main Board
LCD Display Panel
J3
J4J1 J6
Power/Brightness
Switch Board
Backlight Bulb
Connectors
Backlight Bulb
Connectors
J5
J2
Inverter
Board
ADC Cable
