Apple Cinema Display (20-inch) Take Apart
USB Cable Assembly
Procedure
1. Remove four Phillips screws—two on the USB socket and two on the cable clamps.
2. Disconnect the cable connector from the main board and remove the USB cable
assembly.
Note:
Push down on the back end of the tab on the top of the cable connector to
disengage the connector.
Replacement Note:
Transfer the two identical cable clamps to the replacement cable
assembly, if usable, otherwise install new clamps.
