Testing Procedures -
15
iPod mini
Navigation Notes:
• Navigate through the list of tests by using the Next and Previous buttons to move up
and down the list.
• Start a test by pressing the Select button (sometimes referred to as ACTION button).
• Press the Play button to continue, or return to the diagnostics menu list.
• Reset the iPod to leave the diagnostics.
5 IN 1
Note:
This test includes tests for: SDRAM, CHKSUM, RTC, USB, and Backlight.
1. If the tests are all OK, the screen below will be displayed.
• For CHKSUM: ignore this result
• For RTC: the number must be between 0 and 100
• USBPASS must be displayed
2. The backlight must be on during the test. If not, fail the iPod.
RESET
1. Skip this test.
KEY
1. Start the test and press all 5 buttons, in any sequence, within 6 seconds (or will show
KEY FAIL) (
Note:
ACTION indicate the Select button).
5IN1
DRAMPASS
CHKSUM :
9958
RTC :
59
USBPASS
KEY TEST
MENU
ACTION
NEXT PRE
PLAY
KEY PASS
