Mac mini (Late 2009) Take Apart — Audio Board 103
2009-11-03
Removal
Disconnect audio 1
ex cable from
interconnect board.
Remove internal 2
frame.
Note: It’s possible to
remove the audio
board without
removing the internal
frame, but for visual
reference it has been
removed.
Remove 1 screw 3 922-
7325.
