Mac mini (Late 2009) Take Apart — Audio Board 105
2009-11-03
Reassembly
Position audio board 1
ports under metal
tabs on the bottom
housing.
2 Pull back on the metal
tab and seat the
audio board into the
ports on the bottom
housing.
Test the alignment 3
by inserting a
headphone connector
into the headphone
jack.
