Apple Mac Pro - Page 52

Mac Pro (Early 2008)) Take Apart — Front Fan Assembly 52
Procedure
Using a long-handled, magnetized #1 Phillips screwdriver, remove the screw at the top rear 1.
of the front fan assembly that mounts the assembly to the logic board.
Remove the second Phillips screw at the bottom front of the assembly. 2.
