36 Appendix
Display Cable Specifications
m DVI digital-only connector
The digital-only connector contains 24 signal contacts organized in three rows of 8
contacts.
Pin Signal assignment Pin Signal assignment Pin Signal assignment
1TMDS Data2- 9 TMDS Data1- 17 TMDS Data0-
2TMDS Data2+ 10 TMDS Data1+ 18 TMDS Data0+
3TMDS Data2 Shield 11 TMDS Data1 Shield 19 TMDS Data0 Shield
4 No Connect 12 No Connect 20 No Connect
5 No Connect 13 No Connect 21 No Connect
6 DDC Clock 14 +5 V Power 22 TMDS Clock Shield
7 DDC Data 15 Ground (for +5 V) 23 TMDS Clock +
8 No Connect 16 Hot Plug Detect 24 TMDS Clock -
