APPENDIX A
Description of buttons functions in [Geometry] page
1. Preset & read – Preset default (max) Contrast setting and read the parameters values.
2. UUT ON/OFF – Turn ON or OFF the unit. If button shows “UUT OFF” it means that
hitting the button “UUT OFF” will turn OFF the unit. Vice versa for “UUT ON”.
Note: UUT means “Unit-Under-Test”.
3. Load defaults – Load the factory aligned values.
4. Read ALL – Read all the alignment parameters values in the current page.
5. Degauss – Activate the built-in degauss function.
6. Save user – Save the current page’s parameters values into the user EEPROM.
7. Timing – Read what is the current vertical timing frequency of cab1, cab2,….
8. Save defaults – Save the current page’s parameters values into the factory EEPROM.
9. Do Prediction – Predict the other geometry modes parameters based on the alignment
data stored in the Cab_3 timing (1024x768@99Hz prime mode) user EEPROM.
Predicted values for the other timing mode parameters will be stored in the user
EEPROM.
10. Degauss State – Check on the power ON degauss state – i.e. whether power ON
degauss is enabled. Must be enabled.
11. File -> EE – Downloads the file contents (in simple text file format of [address data])
to the EEPROM.
12. EE -> file – Uploads the EEPROM data and stores the data in simple text file format.
Use the check boxes [IVAD Data] or [VPT Data] to select the kind of upload data.
Description of buttons functions in [Color/Convergence] page
Note: Some buttons functions are the same as previous.
1. Save – Save all the current parameters values into user and factory EEPROM.
2. Preset Color – Set the R, G, B drives and cutoffs prior to cutoff and color alignment.
3. Get HiIks – Read the R, G, B high beam currents.
4. Get LoIks – Read the R, G, B low beam currents.
5. Bright Win ON/OFF – Activate/de-activate the bright window feature.
6. Full Screen ON/OFF – Activate/de-activate the theater mode feature. Must be used
with bright window mode ON.
