Undo and remove the two nuts «1» on
the front side and collect the screws.
Undo and remove the two nuts «2» on
the rear side and collect the screws.
Remove the air deflector housing.
Unscrew and remove the two screws
"3".
Remove the electric fan.
ATLANTIC 300 i.e. Cooling system
COOL SYS - 233
