ELECTRICAL SYSTEM
8 - 17
ATLANTIC 125 - 200
Low fuel light test
• Disconnect the sensor connector,
4.1.3.
• Connect an ohmmeter to the orange-black and blue
wire terminals.
• Check for continuity across the terminals when fuel
inside the tank is less than 1.5 litres. With any other
quantity of fuel resistance should be infinite (open
circuit).
Engine oil pressure test
• Disconnect the sensor from the system, see Engine
Workshop Manual
0.1.2.
• With the engine running, there should be no continuity
to ground. If not so, ensure that engine oil level is
correct and replace sensor.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
