APRILIA ATLANTIC 500 sprint User Manual

ROUTINE MAINTENANCE
2 - 22
ATLANTIC 125 - 200
• Raise and remove cover (2).
• Remove gasket (3).
NOTE In order not to spill the brake fluid while topping up, do
not shake the vehicle.
• Top up tank with brake fluid, see
1.8.1., to
correct level.
WARNING
Do not exceed the "MAX" level while topping
up.
It is advisable to top up until reaching the
"MAX" level only with new pads.
When the disc pads wear out, the level of the
fluid decreases progressively to compensate
for their wear.
Do not reach the "MAX" level with worn out
pads, since this will cause a fluid outflow when
the pads are changed.
• To refit components, follow the disassembly procedure
in reverse order.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
