BRAND TYPE RESISTANCE ELECTRODE GAP
(*) NGK IR MR8BI-8 7.5 KOhm (MAX) / 3KOhm (MIN) 0.8 mm (0.031 in)
Data
(*) Alternative solution
ELECTRICAL SYSTEM
Battery 12 V - 10 Ah YTX 12 - BS
Alternative solution:
12 V - 12 Ah YTX 14 - BS
Main fuses 30 A, 5 A
Secondary fuses 7,5 A (2), 10 A, 15 A (3)
ABS fuses 20 A
Alternator (permanent magnet) 13.5 V - 450 W at 6000 rpm
Ignition Electronic, inductive, high
efficiency ignition, integrated with
the injection system, with variable
advance and separate H.V. coil.
Ignition advance Three-dimensional map managed
by control unit.
150
