66
use and maintenance Habana 50/125 - Habana Custom 50/125
2%-/6).'4(%"!44%29x u
Carefully read p. 64 (BATTERY).
PARTIAL REMOVAL
◆
Position the vehicle on the centre stand.
aWARNING
Wait until the engine and the exhaust si-
lencer have completely cooled down.
◆
Make sure that the ignition switch is in
position “
m”.
◆
Working on the right side of the vehicle,
introduce your left hand under the fairing.
◆
Release the belt (1) that holds the bat-
tery.
◆
Move the belt (1) sidewards.
aCAUTION
The battery is connected with the elec-
tric cables. Do not force the cables
while removing it.
◆
Grasp the battery (2) and remove it from
its compartment by withdrawing it from
behind.
COMPLETE REMOVAL
◆
Disconnect first the negative cable (–)
and then the positive cable (red) (+).
◆
Position the battery (2) on a flat surface,
in a cool and dry place.
aWARNING
After removal, the battery must be
stored in a safe place and kept away
from children.
#(%#+).'4(%
%,%#42/,94%,%6%,w v
Carefully read p. 64 (BATTERY).
◆
Remove the battery from its compart-
ment, see beside (REMOVING THE
BATTERY
w v).
◆
Make sure that the fluid level is included
between the two “MIN” and “MAX” notch-
es stamped on the battery side.
Otherwise:
◆
Unscrew and remove the element plugs.
aCAUTION
Top up with distilled water only. Do not
exceed the “MAX” mark, since the elec-
trolyte level increases during the re-
charge.
◆
Top up by adding distilled water.
aCAUTION
After topping up, put back the element
plugs in the correct position.
◆
Put back the element plugs.
