use and maintenance MX 125
KEY
1) 2 stroke oil tank plug
2) 2 stroke oil tank
3) Air cleaner
4) Rear brake fluid tank
5) Fuel cock
6) Brake fluid reservoir (front brake)
7) Ignition switch/steering lock
8) Coolant radiator cap
9) Coolant right radiator
10) Horn
11) Rear brake control lever
12) Rider right footrest
(with spring, always open)
13) Rear brake pump
14) Drive chain
15) Passenger right footrest
(snapping, closed/open)
16) Crash helmet hook
16
15
32
9
8
12 101314
1 4 5 6 7
11
