85
use and maintenance MX 125
TECHNICAL DATA
DIMENSIONS Max. length
(with rear mudguard extension) .................. 2165 mm
Max. width................................................... 840 mm
Max. height (front part of the fairing included) 1170 mm
Seat height.................................................. 870 mm
Distance between centres........................... 1480 mm
Min. ground clearance ................................ 290 mm
Weight ready for starting............................. 126 kg
ENGINE Type ............................................................ One-cylinder, 2-stroke with laminar suction. Separate lubrication
with variable strength automatic mixer (1.0 - 3.0 %).
Number of cylinders .................................... 1
Total displacement...................................... 124.82 cm>
Bore / stroke................................................ 54 mm / 54.5 mm
Compression ratio....................................... 12.5 ± 0.5 : 1
Starting........................................................ with pedal
Engine idling rpm ........................................ 1200 ± 100 rpm
Clutch.......................................................... multidisc in oil bath, with manual control on the left side of the hand-
lebar.
Cooling........................................................ liquid-cooled
CAPACITY Fuel (reserve included) ...............................
11
l
Fuel reserve................................................
1.3
l (mechanical reserve)
Transmission oil.......................................... 600 cm>
Coolant........................................................
0.8
l (50% water + 50% antifreeze with ethylene glycol)
2 stroke oil (reserve included).....................
1.25
l
2 stroke oil reserve......................................
0.5
l
Seats........................................................... 2
Vehicle max. load
(driver + passenger + luggage)................... 336 kg
