APRILIA RS 125 User Manual

CHASSIS
7 - 22
RS 125
7.1.16. UPPER CHAIN SLIDER REMOVAL
TORQUE WRENCH SETTINGS
Screw (1) 2 Nm (0.2 kgm)
Screw (3) 2 Nm (0.2 kgm)
NOTE The chain slider is best accessed after splitting the
drive chain; see
7.13.1.
• Release and remove the screw (1) and collect the nut
(2).
• Release and remove the screw (3) and collect the
grommet (4).
• Remove the upper chain slider (5).
431
5
2

APRILIA RS 125 Specifications

General

Displacement	124.8 cc
Transmission	6-speed
Front Suspension	Upside-down fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Dry Weight	114 kg
Fuel System	Carburetor
Frame	Aluminum perimeter frame
Engine Type	Single cylinder, 2-stroke
