16
use and maintenance RS 50
MAIN INDEPENDENT CONTROLS
NOTE The electrical parts work only when the ignition switch
is in position ≈
∆.
The lighting system works only when the engine is running.
CONTROLS ON THE LEFT PART
OF THE HANDLEBAR
1) HORN PUSH BUTTON (
)
The horn is activated when the push button is pressed.
2) DIRECTION INDICATOR SWITCH ( ( )
To indicate the turn to the left, move the switch to the left; to
indicate the turn to the right, move the switch to the right.
To turn off the direction indicator, press the switch.
3) DIMMER SWITCH ( - )
When it is in position ≈
∆ the parking lights, the dashboard
light and the low beam are always on.
When it is in position ≈∆, the high beam comes on.
NOTE The lights can be switched off only by stopping the
engine.
4) HIGH BEAM SIGNALLING PUSH BUTTON ()
It makes it possible to use the high beam for signalling to
forthcoming vehicles while overtaking and in case of peril
and/or emergency.
5) COLD START LEVER ()
The starter for the cold start of the engine is operated by rotat-
ing the lever "
" downwards. To disconnect the starter, move
the lever "
" to its initial position.
