APT 340XAC Quick Start Guide

CHANGINGTESTMODES
5.
The 300XAC includes two test modes that change the way in which the AC power
source operates. PROGRAM Mode allows the operator to configure and run a test
using steps and memory locations within the AC power source’s menu. PROGRAM
Mode is designed for advanced testing applications. MANUAL Mode doesn’t
utilize steps and memories, allowing the operator to quickly run a test with basic test
parameters.
Turn the POWER switch to ON. From the Set screen press the “<more>” soft key and
press the “System” soft key in the next screen.
In the System Parameters Menu, you can use the up or down arrow soft keys to
highlight the AUTO RUN parameter. To change the AUTO RUN parameter, press the
“Edit” soft key.
In the next screen, the AUTO RUN parameter will be highlighted. Press the
“Change” soft key to toggle the highlighted parameter between PROGRAM and
MANUAL mode. Press the “Enter” soft key to save changes made and then press the
“Exit” soft key two times to return to the Set screen.
When the AUTO RUN parameter in the System Parameters menu is set to PROGRAM
mode, the Set screen will be displayed as follows: (See Figure 1)
(Figure 1. Set Screen)
When the AUTO RUN parameter in the System Parameters is set to the MANUAL
mode the Set screen will be displayed as follows: (See Figure 2)
(Figure 2. Set Screen)
