Installations
1. Detaching /attaching the Protection Cover
Push the handle of the lever in the direction of the arrow shown in the picture, and rotate the cover to
pull it out. Reverse rotation will put the protective cover into.
2. Attaching/detaching the Reflector
Push the lever handle according to the arrow direction shown in the picture, and rotate the reflector
into it. Rotating in the opposite direction pulls out the reflector.
3. Setting up the light
Adjust the lamp body to the appropriate height, rotate tie-down to fix the lamp body on the tripod,
then adjust the lamp body to the required angel, and tighten the lock handle.
1
2
3
Always remove the protection cover prior to turning on the light. Always re-install the cover when
packing it away.
1
2
3
