Aqara Motion Sensor P1 User Manual

04
1.Choose an appropriate installation position and make
sure the installation surface is clean and flat.
Direct Installation
*Recommended installation height is 1.2-2m. The detection scope gets
smaller if it is lower than 1.2m. There will be a blind zone at the bottom of
the motion sensor if it is installed higher than 2m.
2.Put the sticker on the bottom of the battery cover,
determine the detection direction, stick it to the desired
installation position, and press hard and evenly for 30 s to
make sure it sticks firmly.
Effective detection area: Top view
6m 6m0m
7m

Aqara Motion Sensor P1 Specifications

General

Detection Angle	170°
Battery Type	CR2450
Battery Life	Up to 2 years
Connectivity	Zigbee 3.0
Operating Humidity	0-95% RH (non-condensing)
Model	RTCGQ-13LM
Compatibility	Apple HomeKit, Aqara Home, Alexa, IFTTT
Detection Distance	Up to 7 meters (23 feet)
Mounting	adhesive
