Aqua Select 832406KL - Step 1; Step 2; Step 3

3
STEP 1
STEP 2
STEP 3
• Slide one of the four ladder steps(BS MIDSTEP)
onto one of the stainless steel handrails (BS
SSRAIL). Make sure that the step treads are
facing up. (See figure 1)
• If you have any difficulty sliding the step onto
the post, apply a small amount of lubricant to the
posts.
•
Slide
the second handrail thru the hole on the
opposite side of the step.
•
Align the holes in the step with the top set
of holes on the handrail.
•
Secure step to handrail with a bolt and nut
out of hardware bag (BS 698HDWR).
Make sure that the head of the bolt is
located on the outside of the step.
(See figure 2)
• Slide
the remaining 3 steps onto the
handrails and secure them with nuts and
bolts. (See figure 3)
Figure 1
Figure 2
Figure 3
