STEP 1
•
Place the bottom step (AC BTSTEP) on a level surface with
indentations
facing up.
•
Take leg (AC 01129) and stand upright (pointed side down).
When installed on bottom step, the leg will need to have the
raised areas facing inward
. The raised area with the
pre-drilled
screw hole should be at the front of the ladder
toward the top of the leg.
•
Place the left leg into the indentation on the left side of the
step and push straight down until it clicks into place.
• Repe
at above for right leg on right side of step.
STEP 2
• There are two sets of lug locations on the stringers in the
areas where each step will be installed. Each step should
be installed into the UPPER set of lugs only.
• Locate one of the four groups of lugs and slide step
(AC MKSTEP) into the upper set of lugs on the legs so
it clicks into place.
•
Repe
at for each of the remaining (3) steps.
• Secure all by drilling (1) #10 x 1-1/4” screw into each side
of the step through the pre-marked leg openings.
3
The Ladder must be installed based on Manufacturer’s Instructions
•
One person on the Ladder/Stair at a time
• This Ladde
r is designed and manufactured for a specific Pool Wall Height
and/or Deck of the Pool
• For Entry/Exit of pool, face the ladder at all times
• Remove and secure Ladder when pool is not occupied
• The Ladde
r will be suitable up to 54” Maximum Pool Height
• There shall be clearance of Min. 3” and Max. 6” between the Pool Wall and
the Ladder
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ PRIOR TO ASSEMBLY/USE
