10. UF membrane replacement: FP3-4
Shut off water supply valve. Open filter faucet to release pressure from the system.
Push in the flange and pull out flexible tubing.
Remove UF membrane housing from mounting clips.
3
4
1
2
14
Unpack new UF membrane out of plastic foil and remove
end plugs.
Unscrew inlet and out let connectors from the UF
membrane.
Remove all layers of old Teflon tape and apply mutliply
layers of new one.
NOTE! Ensure that Telflon tape is winded in the
opposite direction to the direction connector will be
installed.
5
7
6
8
Connect inlet and outlet connectors to the housing of new
UF membrane.
NOTE! Do NOT remove elbow connector after the
installation has been started. Stopping and removing
(unscrewing) the element may result in inadequate
connection and water leak.
