Insert flexible tubing (all the way) into both ends of UF
membrane.
! Check if inlet/outlet tubings are correctly and
firmly connected. Make sure the tubing is not bent.
NOTE
Open water supply valve.
11
9
10
Push in membrane housing into mouting clips.
WARNING! While installing UF membrane, remember to
keep the proper direction of water flow (indicated by an
arrow on membrane sticker).
WARNING! UF membrane is soaked with a special
conserving solution.
Install the cartridge in the direction of flow, then rinse it for
several minutes before use. Use only with water
microbiologically safe and adequately disinfected.
15
10.1. UF membranes replacment: FP3-HJ-K1
3
4
1
2
Shut off water supply valve. Open filter faucet to release pressure from the system.
Push in the flange and pull out flexible tubing. Remove UF membrane housing from mounting clips.
