Screw chrome-plated adapter onto the shut-off valve to
allow easy SEWBV1414 valve installation and its easy
opening and closing.
Remember to place rubber gaskets in
between the connections.
WARNING!
Wind a few layers of Teflon Tape TAS0003 on shut-off valve
adapter SEWBV 1414.
3
4
6. System Installation - Stage I
WARNING! Manufacturer is not responsible for any damages that result from improper installation or use of system. System
installation should be performed only in temperatures above 2°C (35.6°F).
Unscrew flexible tubing from the shut-off valve (or the
adapter).
Between the shut-off valve and flexible
tubing is a rubber gasket - be sure not to lose it.
WARNING!
Shut off cold water supply valve.
1 2
5
6
Screw SEWBV1414 valve into chrome-plated adapter
FT06.
Connect other end of flexible tubing to the system.
Put the nut on flexible tubing and connect it with
SEWBV1414 valve - push the tubing all the way into the
valve and tighten the nut
WARNING! To seal threaded connections, always use
Teflon tape during installation (does not concern
threads for plastic and faucet nuts).
7
9
