9
8. Technical Data
Gas yield 45 l/h
Largest nozzle size 20G
Number of torches working at same time 1 to 2 (2 with 22G and smaller nozzles
and optional T-piece in gas tube)
Rated voltage 230 V, 50 Hz
Rated current 0.9 A
Rated power consumption 200 VA
Maximum operating pressure 0.20 bar
Number of cells in the gas generator 3
Distilled water consumption 25 ml/h
Flux fluid consumption 7 ml/h
Pressure regulation pressure switch
Overpressure protection safety pressure limiter
Overheating protection thermostat switch
Number of flashback arresters 2
Direct current display LED
Generator tank capacity 0.8 l of electrolyte
Booster tank capacity 0.1 l of flux fluid
Fill level indicator in generator tank generator float
Fill level indicator in booster tank booster float
Dimensions of the unit in cm 45 x 28 x 22
Weight when ready for operation 14 kg
Size Table for Torch Nozzles in mm:
Nozzle No. Inside Diameter Outside Diameter
20G 0.60 0.90
21G 0.50 0.80
22G 0.40 0.70
23G 0.35 0.60
24G 0.30 0.55
25G 0.25 0.50
26G 0.20 0.45
9. Schematic Diagram
A schematic diagram of the unit’s circuitry is shown on the next page.
