AquaSource FP4A4057NP - Connecting Water Lines and Hose

6
ASSEMBLY INSTRUCTIONS
1
1
2
8
To spout
K
K
I
Weight
here
Weight
here
Weight
here
1
2
3
7
L
J
1
1
6
H
2
7. Remove plastic cap from discharge tube (L),
then attach quick connector (J) to discharge
tube (L). Pull down on quick connector (J)
to ensure it is secure.
Note: For removal, see QUICK
CONNECTOR REMOVAL, page 8.
8. Unscrew preassembled screw on weight
(K). Locate lowest point of the hose (I) on
the spout side and attach weight (K) by
reassembling halves and tightening
preassembled screw.
6. Attach supply lines (H) to shut-off valves
(not included) and hand tighten. Using two
wrenches(notincluded),nishwithone-halfturn.
Do not overtighten.
