AquaSource FS3A0000 - Step 4: Mount Dispenser and Base; Step 5: Install Washers and Nuts; Step 6: Attach Quick Connect Adapter

5
ASSEMBLY INSTRUCTIONS
1
2
5
A
B
C
AA
BB
5. Install slotted washer (B), spacer (C), lock nut
(AA) and nut (BB) to the shank on the dispenser
(A).
4. Install the dispenser (A) and the base (D)
through top of the sink (not included).
4
A
D
1
2
6
A
E
6. Attach the quick connect adaptor (E) to the
end of the shank of the dispenser (A).
