AquaTools AT84150 - Specifications

4
38.5"
(978 mm)
Minimum
Service
Height
27.75"
(705 mm)
19.5" Dia.
(495 mm)
15" Dia.
(381 mm)
2.25"
(57 mm)
Inlet
or Drain
2" NPT
2" NPT
Inlet or
Drain
Outlet
2" NPT
Drain
Plug
Lower
Tank
Shell
Safety
Latch
Upper
Tank
Shell
Air Release Valve
(Pressure Gauge
Behind)
2148 1195AT
Posi-Lok™
Ring
4 (28)
2 (14)
6 (41)
8 (55)
10 (69)
12 (88)
14 (97)
16 (110)
18 (124)
Pressure Drop in Pounds per Square Inch (kPa)
10
(38)
20
(76)
40
(151)
60
(227)
80
(303)
100
(378)
120
(454)
140
(529)
160
(606)
Flow in Gallons Per Minute (LPM)
20 (138)
150
(568)
SPECIFICATIONS
FIGURE 1A – Dimensions in inches (mm)
Table 1 - Filter Specifications
Model No.
AT84100 AT84150
Filter Area sq. ft. (m
2
) 100(9.3) 150(14)
Max. Rated Flow GPM (LPM)*
Residential 100(379) 150(568)
Commercial 37(140) 56(212)
Max. Operating Pressure PSI (kPa) 50(345) 50(345)
Max. Continuous Water
Temperature F(C) 104°(40°) 104°(40°)
* For best water clarity and filter cycle length, restrict
water flow to 50 GPM (189 LPM).
FIGURE 2 – Pressure Drop Curve
INLET
INLET
R
E
L
E
A
S
E
R
E
L
E
A
S
E
To Pool
From
Pool
Outlet
Inlet
Pump
Filter
4085 1001
FIGURE 1B – Piping Connections
