11
5 MAINTENANCE
In case of failure, check the fuse and the wiring (Fig. 2).
FAULT CAUSE REMEDY
The LEDs turn on but
are unable to control the
relevant valves
Disconnected connectors • Connect the connectors.
All LEDs are OFF and
the valves do not work
Internal protection is active
before switching the control box on.
If the problem persists, please contact the nearest
Assistance Centre.
Burnt fuse inside electric
• Replace the fuse. If the problem persists, please
contact the nearest Assistance Centre.
Power supply failure • Check power supply.
6 TECHNICAL DATA
Description 4669 series control box
Power supply 12 Vdc (Vmin 9 / Vmax 16)
Max. switching current per each output (section) 3 A
Max. switching current per each output
(Adjustable actuators / Guard actuators)
5 A
Working temperature -20 °C ÷ 55 °C / -4 °F ÷ +131 °F
Stocking temperature -20 °C ÷ 55 °C / -4 °F ÷ +131 °F
Output protection through resettable fuse present
Dimensions 144 x 108 x 110 mm (harness excluded)
Weight 900 ÷ 924 g (according to the type)
7 DISPOSAL AT THE END OF SERVICE
Dispose of the system in compliance with the established legislation in the country of use.
