5
RISKS AND PROTECTIONS BEFORE ASSEMBLY
1) Set mounting rail in cabin and fasten it
with the relevant screws (1), in a position
where VISIO can be easily seen and at
hands' reach, but away from any moving
organs.
2) Secure VISIO to rail and push down
until locked in place.
3) Fasten wiring so that it does not
interfere with any moving parts.
POWER IS SWITCHED OFF; DISCONNECT POWER CABLES IF NEEDED.
power supply
sensors
