arboga E 308 - 6.4.1 E 308 Belt Arm Spare Parts List

18
6.4.1 Spare parts list for E 308 belt arm
Order number
Pos. No.
Description
RIGHT
LEFT
1
Top screw
2078212
2078212
2
Adjusting pipe for belt frame
9480687
9480687
3
Machine screw M4x4 Z
0737618
0737618
4
Lock ring DIM 42, DIN 472
7655123
7655123
5
Bearing 6302 2Z
1462846
1462846
6
Distance pipe ø22/15x10
2155002
2155002
7
Top roll
9480681
9480681
8
Shaft for top roll
2078200
2078200
9
Disc for top roll
9480693
9480693
10
Screw M6x16 CH Z low headed
3316860
3316860
11
Pointed screw M5x10
0737605
0737605
12
Holder for top roll
9480679
9480679
13
Spring for telescope arm
9480694
9480694
14
Pipe for telescope arm
9480682
9480682
15
Spring holder for telescope arm
2078202
2078202
16
Belt release handle M8x30
2078204
2078204
17
Pipe bushing for telescope arm
2078206
2078206
18
Pipe holder for telescope arm
9480692
9480692
19
Split pin ø5x25
2078208
2078208
20
Handle for belt adjustment
2188010
2188010
21
Fittings for telescope arm
1533813
1533813
22
Spring disc DIM 8 Z
0132594
0132594
23
Screw M8x25 CH Z
0120620
0120620
24
Middle ring
4318001
4318001
25
Pointed screw M8x16
2078210
2078210
26
Holder for telescope arm
2078211
2078211
27
Tool rest
0744425
0744409
28
Disc 3/8” Z
0101491
0101491
29
Screw M10x30 Z
0120707
0120707
30
Cover box for belt arm
1533780
1533781
31
Spring disc DIM 5 Z
0102555
0102555
32
Screw M5x10 CH Z
0120628
0120628
33
Felt packing
1533816
1533816
34
Cover plate
1533812
1533812
35
Distance ring ø30/20x6mm
1551176
1551176
36
Collar bushing E 308
0995681
0995681
37
Star handle ø40 M8 DIN 6335
1443593
1443593
38
Auto disc 5/16” Z
0132310
0132310
39
Spark arrester
1533808
1533808
40
Nut M5 Z
0737623
0737623
41
Flange int.
0921572
0921572
42
Contact wheel 200x50x20
1532170
1532170
43
Plan table
1533807
1533818
44
Flange ext.
1105183
1105183
45
Tap
2004899
2004899
46
Graphite pad 50x270
2004898
2004898
47
Nut M20x1.5
0744824
0744816
48
Grinding belt 50x1600 K80
0215080
0215080
49
Screw M8x16 Z
0120510
0120510
50
DN-Bearing ring for belt arm
0747329
0747329
