Arbor Technology EmCORE-i2703 - Jumpers; Connectors Quick Reference

- 6 -
Jumpers/ Connectors Quick Reference
Label Function
JBAT1 Clear CMOS Setting
JRS2 COM2 RS-232/485 Selection
JVLCD1 LCD Voltage Selection
Jumpers
Connectors
Label Function
AC97 Audio Interface Connector
CFD1 CompactFlash Type II Socket
COM1~4 RS-232 Port Connectors
DIO1 Digital I/O Connector
EATX1 ATX Feature Connector
EKB1 External Keyboard Connector
IDE1 Primary IDE Connector
INV1 LCD Inverter Connector
JCOM2 RS-422/485 Connector
TV1 TV-Out Connector
JFRT1 Switches and Indicators
KBM1 Keyboard & Mouse Connector
LAN1 Ethernet RJ-45 Connector
LPT1 Parallel Port Connector
LVDS1 LVDS LCD Connector
PC/104 PC/104 ISA Interface
PWR1 Power Supply Connector
SATA1~2 Serial ATA Connectors
SYSF1 System FAN connector
USB1~3 USB Connectors
VGA1 Analog RGB D-Sub Connector
