ARCAIR SLICE TORCH - Page 14

4-2
SLICE EXOTHERMIC CUTTING EQUIPMENT
89250848
EQUIPMENT
Figure 3: SLICE Battery Box Assembly
CUT
CHARGE
TEST
GOODRECHARGE
STRIKER
TORCH
CUT
CHARGE
TEST
GOODRECHARGE
CUT
CHARGE
TEST
GOODRECHARGE
SWITCH IN TEST POSITION
SWITCH IN CHARGE POSITION
SWITCH IN CUT POSITION
2
Oxygen Valve Lever
SLICE Torch
Collet Ring
Torch Cable
SLICE Striker
Striker Cable
Black Male
Connector
Red Male
Connector
Oxygen Hose
Connection
Figure 2: SLICE Torch and Striker
SLICE ROD
COLLET NUT
OXYGEN LEVER
SHIELD
HANDLE
Figure 1: SLICE Torch Components
