SECTION 5:
CUTTING DATA
The following chart helps determine the best settings for a specific use as a result of extensive labora-
tory testing of the SLICE Equipment to determine the best cutting rates. Actual cutting results obtained
in the field vary due to conditions and experience of the user. Various usages of SLICE Equipment return
various results. Adjust the settings for any use. Use the following chart as a guide.
Oxygen pressure of 80 psi (551.6 kPa) achieves the best cutting. Some operations may require higher or
lower oxygen pressures - minimum 40 psi (275.8 kPa); maximum 100 psi (689.5 kPa). Amperage over
200 amps does not improve cutting speed.
Find the right metal and thickness. For composites or unlisted metals, locate the listed type that most
resembles the material to be cut.
NOTE!
All these cutting values are based on 1/4" (6.4 mm) diameter flux-coated rods. Cutting
rates with 1/4" (6.4 mm) bare rods are slightly less than the values listed in the chart.
5.01 Material Cutting Rates
Material Type Material Thickness
Length of Cut per Inch
Rod Used
Cutting Speed
in(mm) in(cm) in/min cm/min
Carbon Steel
1/8 (3.2) 2.25 (5.7) 72 183
1/4 (6.4) 1.5 (3.8) 52 132
3/8 (9.5) 1.38 (3.5) 42 106
1/2 (12.7) 1.25 (3.2) 35 89
3/4 (19.1) .75 (1.9) 22 56
Stainless
1/8 (3.2) 2.0 (5.1) 65 165
1/4 (6.4) 1.13 (2.9) 36 91
Aluminum
1/4 (6.4) 1.75 (4.4) 58 147
3/8 (9.5) 1.25 (3.2) 38 97
3/4 (19.1) .75 (1.9) 23 58
SAMPLE SELECTIONS:
The approximate cut/inch rod x amount of cut per rod = cut per rod used
Data: Cutting 3/8" (9.5 mm) aluminum with 1/4" (6.4 mm) fluxed rod
1.25" (3.2 cm) x 19" (48.3 cm) = 23.8" (60.5 cm). Approximate cut/min arc time = 38" (97 cm)
Data: Cutting 1/4" (6.4 mm) carbon steel with 1/4" fluxed rod
1.5" (3.8 cm) x 19" (48.3 cm) = 28.5" (72.4 cm). Approximate cut/min arc time = 52" (132 cm)
CUTTING DATA
