ARCAIR SLICE TORCH - Cutting Rod Types and Specs; SLICE Cutting Torches

5-2
SLICE EXOTHERMIC CUTTING EQUIPMENT
89250848
5.02 Cutting Electrode Types
Cutting rates in this chart were obtained using 80 PSI (551.6 kPa) oxygen pressure and 1/4" x 22" (6.4
mm x 559 mm) cutting rods. These rates are averaged values based on multiple cutting tests. Actual
cutting rates may vary due to parameters used and operator expertise.
Part No.
Diameter
in(mm)
Length
in(mm)
Coated or
Uncoated
Package
Quantity
Oxygen
Flow Rate
CFM(CMM)
Burn
Time
(sec)
42-049-002 1/4 (6.4) 22 (559) Coated 25 7.5 (.21) 40-45
42-049-003 1/4 (6.4) 22 (559) Coated 100 7.5 (.21) 40-45
43-049-002 1/4 (6.4) 22 (559) Uncoated 25 7.5 (.21) 40-45
43-049-003 1/4 (6.4) 22 (559) Uncoated 100 7.5 (.21) 40-45
43-049-005 1/4 (6.4) 44 (1117) Uncoated 25 7.5 (.21) 80-90
42-049-005 3/8 (9.5) 18 (457) Coated 50 12 (.34) 30-35
43-049-007 3/8 (9.5) 18 (457) Uncoated 50 12 (.34) 30-35
43-049-009 3/8 (9.5) 36 (914) Uncoated 25 12 (.34) 60-70
5.03 SLICE Cutting Torches
Part No.
Cable
Size
Power Cable
Length
ft(m)
Oxygen Hose
Length
ft(m)
Cutting with Power
Cutting without
Power
03-003-000 #1
10 (3.05) 10 (3.05)
Recommended Can Be Used
03-003-001 #6 Limited Use Only Recommended
03-003-006 #10 Not Recommended Recommended
CUTTING DATA
