BATTERY BOX
1
4
3
8
2
5
6
9
7
10
11
Item No. Part No. Description
1 94-134-032 Back Half Battery Case
2 96-162-752 Circuit Board Assembly
3 96-076-018 Battery Assembly
4 96-169-382 6-Pin Male Connector
5 96-169-374 Red Female Panel Receptacle
6 96-169-375 Black Female Panel Receptacle
7 96-508-041 Meter
8 96-834-347 Toggle Switch
9 94-766-052 Toggle Switch Seal
10 94-766-053 Circuit Breaker Seal
11 94-171-285 Connector Cover
PARTS LISTING
