ALPHA 7/8/9 CD SERVICE MANUALALPHA 7/8/9 CD SERVICE MANUAL
Alpha 7/8/9 Main PCB Parts List
Ref. No. Description Part No.
C2 PPRO 680P 63V 5% RA 2D168
C3 PPRO 680P 63V 5% RA 2D168
C4 ELST NON POLAR 10UF 35V 2U610
C5 PPRO 100P 63V 5% RA 2D110N
C6 PPRO 680P 63V 5% RA 2D168
C7 PPRO 680P 63V 5% RA 2D168
C10 CERD 1N0 63V 2A210
C11 CERD 10N 100V 20% 2A310
C12 CERD 10N 100V 20% 2A310
C13 CERD 33P 63V 2A033
C14 CERD 33P 63V 2A033
C15 CERD 100P 63V 2A110
C16 CERD 100P 63V 2A110
C17 CERD 10N 100V 20% 2A310
C18 CERD 10N 100V 20% 2A310
C19 CERD 10N 100V 20% 2A310
C20 PPRO 680P 63V 5% RA 2D168
C21 ELST NON POLAR 10UF 35V 2U610
C22 ELST 100U 25V 2N710
C23 ELST 100U 25V 2N710
C24 ELST 100U 25V 2N710
C25 ELST 22U 20V OSCON 2P622
C26 ELST 100U 25V 2N710
C27 ELST 10U 50V 2N610
C28 CERD 470P 63V 2A147
C29 ELST 100U 25V 2N710
C32 CERD 10N 100V 20% 2A310
C33 ELST 1M0 25V 2N810
C34 ELST 100U 100V 2N710B
C35 ELST 100U 100V 2N710B
C36 ELST 3M3 25V 2N833
C37 ELST 10U 50V 2N610
C38 ELST 10U 50V 2N610
C39 ELST 100U 25V 2N710
C40 ELST 100U 25V 2N710
C41 ELST 100U 25V 2N710
C42 ELST 100U 25V 2N710
C43 ELST 1M0 25V 2N810
C44 ELST 1M0 25V 2N810
C45 ELST 1M0 25V 2N810
C46 ELST NON POLAR 10UF 35V 2U610
C47 ELST 1M0 25V 2N810
C48 ELST 1M0 25V 2N810
Alpha 7/8/9 Main PCB Parts List
Ref. No. Description Part No.
C49 ELST 10U 50V 2N610
C50 ELST 10U 50V 2N610
C51 ELST 1M0 25V 2N810
C52 CERD 10N 100V 20% 2A310
C53 ELST 22U 20V OSCON 2P622
C54 CERD 10N 100V 20% 2A310
C55 CERD 10N 100V 20% 2A310
C56 ELST 10U 50V 2N610
C102 PPRO 680P 63V 5% RA 2D168
C103 PPRO 680P 63V 5% RA 2D168
C104 ELST NON POLAR 10UF 35V 2U610
C105 PPRO 100P 63V 5% RA 2D110N
C291 CERD 47N 63V 10% 2A347
C292 ELST 100U 25V 2N710
C293 CERD 47N 63V 10% 2A347
C294 CERD 47N 63V 10% 2A347
D1 SSDIODE 1N4148 75V 3A4148
D2 SSDIODE 1N4148 75V 3A4148
D3 SSDIODE 1N4148 75V 3A4148
D4 RECTIFIER 1N4003F 1A 200V 3B4003
D5 RECTIFIER 1N4003F 1A 200V 3B4003
D6 RECTIFIER 1N4003F 1A 200V 3B4003
D7 RECTIFIER 1N4003F 1A 200V 3B4003
D8 RECTIFIER 1N4003F 1A 200V 3B4003
D9 RECTIFIER 1N4003F 1A 200V 3B4003
D10 RECTIFIER 1N4003F 1A 200V 3B4003
D11 RECTIFIER 1N4003F 1A 200V 3B4003
D12 RECTIFIER 1N4003F 1A 200V 3B4003
D13 RECTIFIER 1N4003F 1A 200V 3B4003
D14 RECTIFIER 1N4003F 1A 200V 3B4003
D15 RECTIFIER 1N4003F 1A 200V 3B4003
D16 RECTIFIER 1N4003F 1A 200V 3B4003
D17 ZENER 15V 400MW 3C11504
D18 ZENER 7V5 400MW 3C07504
D19 ZENER 4V7 400MW 3C04704
D20 ZENER 4V7 400MW 3C04704
D21 SSDIODE 1N4148 75V 3A4148
D22 RECTIFIER 1N4003F 1A 200V 3B4003
D23 RECTIFIER 1N4003F 1A 200V 3B4003
D291 SSDIODE 1N4148 75V 3A4148
D292 SSDIODE 1N4148 75V 3A4148
D293 SSDIODE 1N4148 75V 3A4148
D294 SSDIODE 1N4148 75V 3A4148
