ALPHA 9/9P SERVICE MANUALALPHA 9/9P SERVICE MANUAL
R511 RES MF W4 18K 1% 1H318
R512 RES MF W4 18K 1% 1H318
R513 RES MF W4 33K 1% 1H333
R514 RES MF W4 47K 1% 1H347
R515 RES CF 1W 1K0 5% 1E210
R516 RES CF 1W 1K0 5% 1E210
R517 RES CF 1W 2K7 5% 1E227
R518 RES CF 1W 2K7 5% 1E227
R519 RES CF 1W 330R 5% 1E133
R520 RES CF 1W 330R 5% 1E133
R524 RES MF W4 18K 1% 1H318
R525 RES CF W2 100R 5% 1D110
R526 RES CF W2 100R 5% 1D110
R527 RES MF W4 10R 1% 1H010
RA1 RES MO 3W 5% 0R22 KOASPR3 1Q922
RA101 RES MO 3W 5% 0R22 KOASPR3 1Q922
RLY501 RELAY G5Z-2A-E 24V A207
RLY502 RELAY G5Z-2A-E 24V A207
SK305 PHONO SKT 4-WAY EMC GOLD 8D225
SK501 BINDING POST 4WAY GOLD LTS04102002G 8D416
SK502 BINDING POST 4WAY GOLD LTS04102002G 8D416
SK503 IEC MAINS CONN PCB INS PX 8A001
SK504 STEREO JACK PCB 8D301
SPRFS SPARE FUSE 20mm 1.6A AS C12166
SPRFS SPARE FUSEHOLDER F062
SW501 SW PUSH 2PCO A1008
SW502 SW PUSH 2PCO A1008
SW503 SWITCH PUSH MAINS OPST SDS3P A1006
TC1 TRANSFORMER CLAMP E00201
TC2 TRANSFORMER CLAMP E00201
TH501 THERMISTOR SIEMENS B59008 1T002
TX1 ALPHA9 MULTI VOLTAGE TRANSFORMER L817TX
Y2 TX WIRE RESTRAINT F185
Y3 TX WIRE RESTRAINT F185
Y20 COPPER RIVET HP007
Y21 COPPER RIVET HP007
Z1 IC AUDIO NE5534N 5A5534
Z3 IC COMPARITOR DUAL LM393A 5M393A
Z101 IC AUDIO NE5534N 5A5534
Z201 IC VREG POS LM317T 5D317T
Z202 IC VREG POS LM337T 5D337
Z501 IC COMPARITOR TA7317P 5M7317
Alpha 9P Non PCB Parts, Metalwork etc.
Part No. Description
8K006 U-LINK
E802CH CHASSIS
E802MI PCB INSULATOR
E803SP ALPHA 9/9P AMP SUBPANEL
E804AP FELT RING
E804CP ALPHA 9/9P COVERPLATE
E809RP REAR PANEL
E814FP ALPHA 9P FASCIA
E815PM POWER BUTTON
E822PM FOOT
E825PM ALPHA 9 BADGE
E901HK HEATSINK ANODISED
F037 TOROIDIAL TRANSFORMER CLAMP
F038 RUBBER WASHER FOR ABOVE
HA6K55A TRANSFORMER BOLT
SH053 OWNERS HANDBOOK
SH058 WARRANTY LEAFLET
