ALPHA 9/9P SERVICE MANUALALPHA 9/9P SERVICE MANUAL
Alpha 9 Integrated Amplifier Parts List
Ref. No. Description Part No.
C1 ELST 100U 25V 2N710
C2 PEST 47N 63V 5% 2K347
C3 ELST 100U 100V 2N710B
C4 PCRB 100N 100V 5% RA 5mm 2H410
C5 PPRO 680P 5% 63V RA 2D168
C6 PSTY 56P 160V ENCAP 1PF% 2F056
C7 ELST 10U 50V 2N610
C8 ELST 100U 25V 2N710
C9 PEST 15N 63V 5% 2K315
C10 PEST 15N 63V 5% 2K315
C11 PPRO 220P 5% 63V RA 2D122
C12 ELST NON POLAR 10UF 35V 2U610
C13N PPRO 220P 5% 63V RA 2D122
C14N PPRO 220P 5% 63V RA 2D122
C15N ELST 10U 50V 2N610
C16N PCRB 100N 100V 5% RA 5mm 2H410
C17N PCRB 100N 100V 5% RA 5mm 2H410
C18N PPRO 100P 63V 5% RA 2D110N
C19N PPRO 100P 63V 5% RA 2D110N
C20 PEST 15N 63V 5% 2K315
C21N ELST 10U 50V 2N610
C22 PCRB 100N 100V 5% RA 5mm 2H410
C23 PCRB 100N 100V 5% RA 5mm 2H410
C25N PPRO 2N2 5% 63V RA 2D222
C26N ELST 10U 50V 2N610
C71 ELST 10U 50V 2N610
C72 ELST 100U 25V 2N710
C101 ELST 100U 25V 2N710
C102 PEST 47N 63V 5% 2K347
C103 ELST 100U 100V 2N710B
C104 PCRB 100N 100V 5% RA 5mm 2H410
C105 PPRO 680P 5% 63V RA 2D168
Alpha 9 Integrated Amplifier Parts List
Ref. No. Description Part No.
C106 PSTY 56P 160V ENCAP 1PF% 2F056
C107 ELST 10U 50V 2N610
C108 ELST 100U 25V 2N710
C109 PEST 15N 63V 5% 2K315
C110 PEST 15N 63V 5% 2K315
C111 PPRO 220P 5% 63V RA 2D122
C112 ELST NON POLAR 10UF 35V 2U610
C113N PPRO 220P 5% 63V RA 2D122
C114N PPRO 220P 5% 63V RA 2D122
C115N ELST 10U 50V 2N610
C116N PCRB 100N 100V 5% RA 5mm 2H410
C117N PCRB 100N 100V 5% RA 5mm 2H410
C118N PPRO 100P 63V 5% RA 2D110N
C119N PPRO 100P 63V 5% RA 2D110N
C120 PEST 15N 63V 5% 2K315
C121N ELST 10U 50V 2N610
C122 PCRB 100N 100V 5% RA 5mm 2H410
C123 PCRB 100N 100V 5% RA 5mm 2H410
C125N PPRO 2N2 5% 63V RA 2D222
C126N ELST 10U 50V 2N610
C172 ELST 100U 25V 2N710
C173 ELST 100U 25V 2N710
C201 ELST 10m 50V RA 32mm 2N910
C202 ELST 10m 50V RA 32mm 2N910
C205 PPRO 4N7 63V 5% RA 2D247N
C206 PPRO 4N7 63V 5% RA 2D247N
C207 ELST 10U 50V 2N610
C208 ELST 10U 50V 2N610
C209 ELST 10U 50V 2N610
C210 ELST 10U 50V 2N610
C301N CERD 1N0 63V 20% RA 2A210
C401N ELST 1M0 25V 2N810
